We are a trusted manufacturer and supplier of Automatic Granules Packing Machine. Our products are customized according to the requirements of our customers. This packing machine is used for the packaging of food, tea, cereals, masala and many more. These machines are featured for their robust construction, magnificent performance and low maintenance. Automatic Granules Packing Machine is manufactured using high-grade quality material to meet industry standards. Our customers can avail these at economical prices from us.

We offer Granule Machines ideal for packing of granule such as sugar, rice and pulses etc. Automatic granule packaging machine adopts PLC control bag length regulation and adjustable volumetric cups for measurement. It is suitable for heat sealable compound materials such as single Paper/PE, Cellophane/PE, Aluminum foil /PE, BOPP/PE, Nylon/PE etc.

Granule Packing Machine Show

Granule Packing Machine Applications

Durable, compact VFFS bagger fits into tight spaces and tight budgets! This vertical packaging machine is perfect for packaging snacks and coffee.

The versatility of ZVF Series VFFS bag maker is range from "tube nut" style bags up to jumbo bag, the success of products depending on highly attractive packaging aesthetics. Suitable for packing potato chips, biscuit, pasta, peanuts, nuts, coffee, beans, popcorn, cereals, extruded snacks, confectionery, dreied & freozen fruits, pets food, vegetables, pills, electronics, plastics, hardware, toys and other granular food & non-food products.

Granule Packing Machine Features

Below you will find features of the Mercury vertical bagging machine.

Stainless steel construction

Small foot print

Speeds up to 130 BPM

Bag width from 2"(51mm) to 11"(280mm)

Bag length from 3"(76mm) to 15.75"(400 mm) on a single pull

High speed stepper electric "SmartJaw" ST horizontal sealing system

Self-centering film drive down system

Allen Bradley MicroLogix 1200 PLC control system

5.7" Color Touchscreen

Bilingual operator interface (English/Spanish)

Four zone temperature control within PLC

Automatic edge guide film tracking system, Encoder and registration sensor standard

Short travel, angled incline film unwind system

Tool-Free quick change core chucks

Modular, non-proprietary design

CE - Certificate of Conformity, Certificate of Incorporation (available as an option)

Technical Data

ModelZVF-260G
Bag TypePillow bag, Gusseted bag/Flat bottom bag
Operation ModeIntermittent
SpeedUp to 100 bags/min
Bag Length50-340mm
Bag Width80-260mm
Reel Film Width420mm
Film Thickness0.04-0.12mm
Reel Outer DiaФ450mm
Reel Inner DiaФ75mm
VoltageAC 220V/ 50HZ,1phase or per customer needs
Power Consumption3KW
Compressed Air Requirement0.6MPa,0.36 M3 / Min
Dimension1600x1217x1680mm(L x W x H)
Weight800KG


Automatic Sugar Sachet Granule Packing Machine is suitable for all types of tiny particles of packaging,with three sides sealing bag closure molding and precise positioning sealing and cutting systems,micro-controller with rotary cup feed metering mode,by adjusting the size of the cup volume method reached under the precise control of quantity,automatic measurement and automatic filling purposes.Widely used in foods,medicine,chemical industry and other consumer products and automatic packaging.

This granule packing machine is made of stainless steel or stoving varnish with stable performance,lower consumption,high efficiency, safety and cleanness,it's an ideal equipment which can be used for packing food,tea,herb,dry powder,granules,seeds,grain,wheat,beans,small hardware and components etc.

Iapack Granule Packing Machine Advantage

A. Automatic mini granule packing machine is the new style equipment,that it can pack dry powder,tea powder, tea leaves, small beadss etc. it includes semi automatic filling machine and automatic bag maker, with reasonable structure, stable performance. It complete tea filling and sealing in one.

B. Automatic mini granule packing machine adopts microcomputer control technology, automatic temperature control, automatic bag length setting, automatic feeding film to achieve optimal packing effect.

C.The automatic mini granule packing machine just adopts a data cable to connect the filling machine and automatic bag maker, reducing the malfunction. Greatly improving the working efficiency

D. Adopts high quality imported chip and longer life,high precision, high speed, user friendly design,the mini granule packing machine is easy to operate.

E. Computer intelligence clear material, reducing time-consuming

F. Screw feeding material, high precision, without prejudice broken material

G. Multiple shock absorption structures, mini granule packing machine running smoothly, low noise.

F. This automatic mini granule packing machine suit for many different kind of teas, such as powder tea, tea leaf, small granule material, etc.
